的用途与详细介绍/Brief Introduction：

该产品选取特定三通管包装阀，常使用水剂和膏霜类好产品的包装，相当对高粘稠度原辅材料（如浓酱、尖椒酱、番茄酱、种衣剂、微乳剂、透明桌面剂等）的效率较为特别，且精准度就越高。该产品选取PLC可c语言编程设定，并配64英寸摸屏人与机器画面软件系统，实施定时化进瓶，定时化包装，定时化出瓶，电器产品，自动元零部件均选取國际大品牌，有效有效确保了出众的的品质和牢固稳定的的功能。本产品成分简洁明了，的操作方面，是中国梦想的争对高粘稠度原辅材料的包装产品。该产品购置了控制滴漏问题问题与金属拉丝工艺的包装闷头，有效有效确保包装结束之后后无滴漏问题问题，无金属拉丝工艺。Filling valve, the machine USES special tee is suitable for the filling agent and cream products, especially for high viscosity material (such as thick sauce, chili sauce, tomato sauce, indicated, micro emulsion, suspending agent, etc.) of the effect is obvious, and high precision. The machine USES PLC programmable control, with 6 inch touch screen man-machine interface system, implements the automatic into the bottle, automatic filling, automatic bottle, electric, pneumatic components adopt international brand, to ensure that the performance of the outstanding quality and lasting stability. This equipment has simple structure, convenient operation, is the ideal filling equipment for high viscosity material. The machine is equipped with prevent drip with wire filling cocks, ensure filling after the completion of a drip-tight, no drawing.

优缺点/Characteristic：

◆的操控体系——用到三菱PLCPLC的操控体系，装罐的用药量随意稍微调一下。Control system adopt mitsubishi PLC control system, filling dose random tweaks◆基本实际操作接面——69英寸彩屏手触式基本实际操作接面，更直观简短、安全的靠得住Interface - 6 inches color hand touch interface operation, intuitive and simple, safe and reliable◆效果提高——切料有防滴漏问题试验装置，可表明原辅材料特征符合下潜灌装设备效果。（此效果可所采用）Improvements - blanking drip tight device, according to the material properties have diving filling function. (this function can be chosen)◆电元器件——均所采用亚太老牌企业，抓实机器设备的安全可信可信、精准的高朝；Electrical components adopt international famous brand, to ensure the equipment safe and reliable, high accuracy;◆机械性主件——刷卡机主件均主要包括优良304不锈不锈钢材质钢板网作,假如需用接觸货位能主要包括316L另结算用。Mechanical parts, machine parts are made of high quality 304 stainless steel material can be used if necessary contact 316 l in extra costs.◆运算法的检测——实时视频运算法，对运行出现形象化反应。Counting test, real-time, intuitive reflect the yield of work.◆装灌检查——无瓶不灌、瓶数不怎么不灌Bottle filling test - no bottle no filling, not enough◆保养环境——超声波焊接机包含GMP想要，可简单拆解、家电清洗保养。Maintenance - the machine is in line with the GMP requirements, easy disassembly, cleaning maintenance.◆懂得调整产品型号规格——换成灌装线产品型号规格时，只需要简洁懂得调整，轻易追到。Changing specifications - change the filling specifications, simply adjust, easy fix.◆绿色设备——设备了绿色框架的，使电脑的操作方法学习环境更好保洁卫生学。（此绿色设备可不可以配置）Environmental protection configuration, configuration framework of environmental protection, make the operation of the machine environment more clean sanitation. (the environmental protection configuration can be selected)

水平技术指标/technical parameters：

分装头数The number of filling head	8头（供选择4、6、8、10、1俩个灌装设备头ꦡ）8 head (optional 4, 6, 8, 10, 12 filling head)
应用瓶径 Applicable bottles Drive	Ф33-Ф100 mm
测量表面粗糙度measure precision	±1%
罐装储存量Canned capacity	150-1000ml
工作特性Production Capacity	2400-4000瓶/小的时候2400-4000   bottles per hour
气源压力bleed pressure	0.7-0.9mpa
电    源Power Supply	380 伏/50 HZ
总 功 率The total power	0.5 kw
外形尺寸 boundary dimension	6000×850×1800 mm
重    量Weight	500kg
