功能与详细资料/Brief Introduction：

全重新注塞泵式膏体酱装灌机这是装修公司顺应市场中供给联合开发的新產品。设备采取SUS304不锈钢304注塞泵式计算泵来执行装灌，且集重新上盖、重新旋盖、建筑机电电子商务为成一体，经济实惠操作，占地赔偿占地小，宽泛操作于制作药品、食品厂、药剂、化工公司、彩妆品等职业的液设计，合乎GMP规范化条件。Automatic plunger paste paste filling machine is my company to meet the market demand, introduction of foreign advanced technology to develop new products. This machine adopts SUS304 stainless steel plunger metering pump filling, cover and set for automatic, automatic screw cap, integration of the mechanical and electrical, economical and practical, cover an area of an area small, widely used in pharmaceutical, food, pesticides, chemical industry, cosmetics and other industries of liquid packaging, full compliance with GMP requirements.

特别/characteristic：

◆选用柱塞泵式计量校准泵完成灌装设备，支持所有胶状度固体，要求高；泵的结构设计选用快接式卸下来组织，于的洗涤、杀菌消毒。Adopt plunger type metering pump filling, used various viscosity liquid, high precision; The structure of pump adopts fast disassembly institutions, easy cleaning and disinfection◆注塞泵式压力容器检验泵活塞环环质量会根据相关行业及液體营养成分的各不相同适用硅塑料，四氟乙稀或另一质量，唯一性情况下适用淘瓷质量。Plunger metering pump piston ring material according to the industry and different adopt silicon rubber, liquid ingredients tetrafluoroethylene or other material, special occasions with ceramic material◆PLC调控操作系统，变频式变频调速，自動化层次高。PLC control system, frequency control of motor speed, a high degree of automation◆缺瓶不装灌，会自动记数工作。Lack of bottle filling, automatic counting function◆装量懂得調整更方便，可是一次懂得調整任何收费泵的充填量，也可对於每个收费泵开始微幅懂得調整；操作使用用简，懂得調整尽快。The load adjustment is convenient, can be a filling quantity of all pumps also can be slightly adjusted according to various metering pump; Simple operation, rapid adjustment◆装灌针头包括防滴漏问题试验装置，充填时突入瓶底装灌，缓缓变高，避免 强力气泡。Filling needles a drip-proof device, filling into the bottom of the bottle filling, slowly rising and prevent bubbles.◆空机可适用人群各种不同规格型号的水瓶座，懂得调整简便计算，可在短期间内完成任务。The machine is suitable for various specifications of bottles, easy adjustment, it can be finished in a short period of time◆整体按GMP需要制定。The machine designed according to the requirements of GMP

技术水平运作/technic parameter：

用于瓶盖尺寸规格Size of bottles	20-1000ml（依照规定订做）20-1000 - ml (according to your need）
适于塑料瓶直劲Apply the bottle diameter	¢20-¢150mm
可用盖子外形尺寸Apply the lid specifications	¢20-¢70mm
产出功能 production capacity	四头灌装线：1000-2500瓶/分钟 Four filling head: 1000-2500 bottles per hour 八头装灌：2500-4000瓶/h Eight head filling: 2500-4000 bottles per hour 12头包装：4000-6000瓶/h 12 head filling: 4000-6000 bottles per hour
装量误差率The load error	±1%
旋盖良好率率Screw cover percent of pass	≥99%
24v电源power supply	380V，50HZ
耗油率power	3.0KW
源gas sources	0.4-0.75MPA
极限速度掌握speed control	直流变频空调调压variable speed
